Colored Optical Glass

Green Glass

Green Glass

Detail Inquiry
Green Glass

Green Glass Characteristic
Type Thickness A[2856k] D65 Chemical Stability ND A×10-7 Tg Ts S
(mm) x y y x y y DA DW (/℃) (℃) (℃)
LB1 2 0.328 0.593 24.6 0.268 0.586 28.2 1 3 1.524 96 535 599 2.52
LB2 2 0.25 0.669 9.7 0.216 0.658 11.9 1 2 1.524 96 535 599 2.52
LB3 2 0.252 0.502 23.7 0.196 0.374 29.3 1 1 1.523 98 526 597 2.52
LB4 2 0.23 0.516 16.3 0.183 0.387 20.7 1 1 1.523 89 525 598 2.52
LB6 2 0.426 0.468 71.9 0.32 0.424 73.6 6 5 1.534 100 421 463 2.83
LB7 2 0.36 0.603 25.6 0.308 0.629 28.4 1 2 1.547 104 458 526 2.85
LB8 2 0.496 0.459 34.9 0.42 0.475 32.3 1 2 1.523       2.52
LB9 2 0.462 0.452 86.7 0.353 0.429 85.2 1 2 1.547 104 458 526 2.85
LB10 2 0.472 0.477 79.2 0.383 0.495 77.6 1 3 1.547 104 458 526 2.85
Technical Indexes
Type Thickness 430 450 520 530 650
(mm) (nm) (nm) (nm) (nm) (nm)
LB1 2 ≤0.4     ≥41.9 ≤3.2
LB2 2   ≤0.2   ≥18.3 ≤0.2
LB3 2   15.2~29.0 ≥40.0   ≤1.7
LB4 2   6.0~15.9 ≥24.1   ≤0.2

Technical Indexes
Type Thickness 400 420 460 480 550 560 620 650 660
(mm)  (nm) (nm) (nm) (nm) (nm) (nm) (nm) (nm) (nm)
LB6 2       41.7~50.1       ≥79.4       25.1~33.1
LB7 2               ≤8.0  545   ≤8.0
32.0-45.0
LB8 2    ≤1.3             30.3~43.9     640
25.2-40.0
LB9 2 ≤2.0          ≥82.0      65.0~70.0
LB10 2   ≤1.0        ≥72.0      50.0~60.0



Class Of Bubble, Stripe, Stress
Type Bubbles Stripe Stress
LB1 C-B 4 3
LB2 C-B 4 3
LB3 C-B 4 3
LB4 C-B 4 3
LB6 C 3C 4
LB7 C-B 3C 3
LB8 C-B 3C 3
LB9 C-B 3C 3
LB10 C-B 3C 3





Green Glass Characteristic
Type Thickness A[2856k] D65 Chemical Stability ND A×10-7 Tg Ts S
(mm) x y y x y y DA DW (/℃) (℃) (℃)
LB11 2 0.435 0.528 53 0.364 0.56 54.4 1 2 1.547 104 458 526 2.85
LB12 2 0.463 0.433 87.3 0.342 0.388 84.9 3 4 1.536 95 534  606 2.73
LB13 1 0.352 0.568 15.1 0.284 0.554 16.9 1 3 1.527 98 597 663 2.53
LB14 1 0.369 0.576 8.9 0.307 0.588 9.8 1 3 1.527 98 597 663 2.53
LB15 1 0.351 0.601 2.2 0.299 0.617 2.5 1 3 1.527 98 597 663 2.53
LB16 2 0.484 0.476 74 0.405 0.483 70.2 6 5 1.535 100 421 463 2.84
LB17 2 0.434 0.518 56.4 0.356 0.541 58 1 2 1.547 104 458 526 2.85
LB18 2 0.377 0.543 40.9 0.299 0.536 44.8 1 2 1.547 104 458 526 2.85
LB19 2 0.161 0.525 2.7 0.143 0.399 3.7 1 3 1.544 96 535 599 2.52



Technical Indexes
Type Thickness 360 420 480 540 550 620 650 680
(mm)  (nm) (nm) (nm) (nm) (nm) (nm) (nm) (nm)
LB11 2     ≤0.4    ≥65.0         17.0~24.0
LB12 2 ≤0.8          ≥79.4
LB13 1     ≤13.8 17.4~30.3     ≤12.6 ≥72.5
LB14 1     ≤7.6 7.6~17.4   ≤8.1
LB15 1     ≤3.2 ≥2.0   ≤4.2



Technical Indexes
Type Thickness 450 460 510 520 530 560 600 660 750
(mm)  (nm) (nm) (nm) (nm) (nm) (nm) (nm) (nm) (nm)
LB16 2   9.0~16.0       ≥83.6    35.0~42.0
LB17 2 ≤1.5       ≥68.0   ≤46.0   ≤20.1
LB18 2 ≤32.8     ≥62.8     ≤18.5   ≤2.1
LB19 2   ≤3.0 6.0~10.0     ≤2.5



Class Of Bubble, Stripe, Stress
Type Bubble Stripe Stress
LB11 C-B 3C 3
LB12 C-B 3C 3
LB13 C-B 4 3
LB14 C-B 4 3
LB15 C-B 4 3
LB16 D-C 3C 4
LB17 C-B 3C 3
LB18 C-B 3C 3
LB19 C-B 4 3
